flatMap() and the order of events - RxJava FAQ

Parc de la Tête d'Or, Lyon
As we already discovered, flatMap() does not preserve the order of original stream. Let's illustrate this using the GeoNames API example from previous article:
public interface GeoNames {

    Flowable<Long> populationOf(String city);

}
By requesting population of multiple cities using flatMap() we have no guarantee that they will arrive in order:

Flowable<String> cities = Flowable.just("Warsaw", "Paris", "London", "Madrid");

cities
        .flatMap(geoNames::populationOf)
        .subscribe(response -> log.info("Population: {}", response));
The output is somewhat surprising:

17:09:49.838 | Rx-3 | --> GET .../searchJSON?q=London http/1.1
17:09:49.838 | Rx-1 | --> GET .../searchJSON?q=Warsaw http/1.1
17:09:49.838 | Rx-4 | --> GET .../searchJSON?q=Madrid http/1.1
17:09:49.838 | Rx-2 | --> GET .../searchJSON?q=Paris http/1.1
17:09:49.939 | Rx-4 | <-- 200 OK .../searchJSON?q=Madrid (98ms)
17:09:49.939 | Rx-3 | <-- 200 OK .../searchJSON?q=London (98ms)
17:09:49.956 | Rx-3 | Population: 7556900
17:09:49.958 | Rx-3 | Population: 3255944
17:09:51.099 | Rx-2 | <-- 200 OK .../searchJSON?q=Paris (1258ms)
17:09:51.100 | Rx-1 | <-- 200 OK .../searchJSON?q=Warsaw (1259ms)
17:09:51.100 | Rx-2 | Population: 2138551
17:09:51.100 | Rx-2 | Population: 1702139
After some time we receive response for Madrid followed by London which are later received by subscriber. 7556900 (population of London) and 3255944 (Madrid) come first After a while Paris and Warsaw arrive as well. On one hand it's good that we can proceed with each population immediately when it arrives. This makes the system seem like more responsive. But we lost something. The input stream was "Warsaw", "Paris", "London", "Madrid" whereas the resulting stream contains population of "London", "Madrid", "Paris", "Warsaw". How can we tell which number represents which city?

Obviously the following solution is plain wrong, yet it's not unheard of in real code bases:

Flowable<Long> populations = cities.flatMap(geoNames::populationOf);
cities
        .zipWith(populations, Pair::of)
        .subscribe(response -> log.info("Population: {}", response));
It compiles, it runs, it even produces some results. Unfortunately these results are entirely wrong:

17:20:03.778 | Rx-2 | --> GET .../searchJSON?q=Paris http/1.1
17:20:03.778 | Rx-3 | --> GET .../searchJSON?q=London http/1.1
17:20:03.778 | Rx-4 | --> GET .../searchJSON?q=Madrid http/1.1
17:20:03.778 | Rx-1 | --> GET .../searchJSON?q=Warsaw http/1.1
17:20:03.953 | Rx-4 | <-- 200 OK .../searchJSON?q=Madrid (172ms)
17:20:03.959 | Rx-2 | <-- 200 OK .../searchJSON?q=Paris (179ms)
17:20:03.975 | Rx-2 | Population: (Warsaw,2138551)
17:20:03.976 | Rx-2 | Population: (Paris,3255944)
17:20:03.988 | Rx-3 | <-- 200 OK .../searchJSON?q=London (207ms)
17:20:03.988 | Rx-3 | Population: (London,7556900)
17:20:04.080 | Rx-1 | <-- 200 OK .../searchJSON?q=Warsaw (299ms)
17:20:04.080 | Rx-1 | Population: (Madrid,1702139)
We combine cities with some random permutation of their population's. To make matters worse I managed to get wrong results after maybe dozen attempts. For some reason this program was working on my machine most of the time. Worst kind of bug you can imagine.

The problem with flatMap() is that it looses the original request. Imagine an asynchronous system where you receive a response on some sort of queue but have no idea what the request was. An obvious solution is to somehow attach some sort of correlation ID or even the whole request to the response. Unfortunately populationOf(String city) doesn't return the original request (city), only response (population). It would be so much easier if it returned something like CityWithPopulation value object or even Pair<String, Long>. So now imagine we are enhancing the original method by attaching the request (city):

Flowable<Pair<String, Long>> populationOfCity(String city) {
    Flowable<Long> population = geoNames.populationOf(city);
    return population.map(p -> Pair.of(city, p));
}
We can now take advantage of this method for larger stream of cities:

cities
        .flatMap(this::populationOfCity)
        .subscribe(response -> log.info("Population: {}", response));
...or to avoid extra helper method:

    cities
            .flatMap(city -> geoNames
                    .populationOf(city)
                    .map(p -> Pair.of(city, p))
            )
            .subscribe(response -> log.info("Population: {}", response));
The result variable this time is Pair<String, Long> but you are encouraged to use more expressive value object.

17:20:03.778 | Rx-2 | --> GET .../searchJSON?q=Paris http/1.1
17:20:03.778 | Rx-3 | --> GET .../searchJSON?q=London http/1.1
17:20:03.778 | Rx-4 | --> GET .../searchJSON?q=Madrid http/1.1
17:20:03.778 | Rx-1 | --> GET .../searchJSON?q=Warsaw http/1.1
17:20:03.953 | Rx-4 | <-- 200 OK .../searchJSON?q=Madrid (172ms)
17:20:03.959 | Rx-2 | <-- 200 OK .../searchJSON?q=Paris (179ms)
17:20:03.975 | Rx-2 | Population: (Paris,2138551)
17:20:03.976 | Rx-2 | Population: (Madrid,3255944)
17:20:03.988 | Rx-3 | <-- 200 OK .../searchJSON?q=London (207ms)
17:20:03.988 | Rx-3 | Population: (London,7556900)
17:20:04.080 | Rx-1 | <-- 200 OK .../searchJSON?q=Warsaw (299ms)
17:20:04.080 | Rx-1 | Population: (Warsaw,1702139)
I found flatMap() with nested map() adding additional context to be the most effective way of dealing with out-of-order results. Surely it's not the most readable piece of reactive code so make sure you hide this complexity behind some facade.

UPDATE

As noted by Dávid Karnok in his comment to this post, the map() operator inside flatMap() is such a common idiom that a specialized flatMap() overload exists. Apart from standard transformation function (in our case String -> Flowable<Long>) it also takes combiner bi-function (e.g. (String, Long) -> SomeType). The purpose of this function is to provide a transformation that combines input item with each output item generated by transformation. This is precisely what we did with nested map() (enriching population with the name of city it corresponds to), but much shorter:

Flowable<Pair<String, Long>> populations = cities
        .flatMap(city -> geoNames.populationOf(city), (city, pop) -> Pair.of(city, pop));
The second lambda expression ((city, pop) -> Pair.of(city, pop)) is executed for every downstream event produced by populationOf(). If you go to the extreme, you can use method references:

Flowable<Pair<String, Long>> populations = cities
        .flatMap(geoNames::populationOf, Pair::of);
Take a moment to study the last example, it's actually beautifully simple once you grasp it:

  • for each city find its population pop
  • for each population combine it with city by forming a Pair<String, Long>


PS: This was 200th post in 9 years!
