Standalone web application with executable Tomcat

Oslo City Hall from Tjuvholmen
When it comes to deploying your application, simplicity is the biggest advantage. You'll understand that especially when project evolves and needs some changes in the environment. Packaging up your whole application in one, standalone and self-sufficient JAR seems like a good idea, especially compared to installing and upgrading Tomcat in target environment. In the past I would typically include Tomcat JARs in my web application and write thin command-line runner using Tomcat API. Luckily there is a tomcat7:exec-war maven goal that does just that. It takes your WAR artifact and packages it together with all Tomcat dependencies. At the end it also includes Tomcat7RunnerCli Main-class to manifest.

Curious to try it? Take your existing WAR project and add the following to your pom.xml:

<plugin>
    <groupId>org.apache.tomcat.maven</groupId>
    <artifactId>tomcat7-maven-plugin</artifactId>
    <version>2.0</version>
    <executions>
        <execution>
            <id>tomcat-run</id>
            <goals>
                <goal>exec-war-only</goal>
            </goals>
            <phase>package</phase>
            <configuration>
                <path>/standalone</path>
                <enableNaming>false</enableNaming>
                <finalName>standalone.jar</finalName>
                <charset>utf-8</charset>
            </configuration>
        </execution>
    </executions>
</plugin>
Run mvn package and few seconds later you'll find shiny standalone.jar in your target directory. Running your web application was never that simple:


$ java -jar target/standalone.jar
...and you can browse localhost:8080/standalone. Although the documentation of path parameter says (emphasis mine):

The webapp context path to use for the web application being run. The name to store webapp in exec jar. Do not use /
just between the two of us, <path>/</path> seems to work after all. It turns out that built in main class is actually a little bit more flexible. For example you can say (I hope it's self-explanatory):

$ java -jar standalone.jar -httpPort=7070
What this runnable JAR does is it first unpacks WAR file inside of it to some directory (.extract by default1) and deploys it to Tomcat - all required Tomcat JARs are also included. Empty standalone.jar (with few KiB WAR inside) weights around 8.5 MiB - not that much if you claim that pushing whole Tomcat with every release alongside your application is wasteful.

Talking about Tomcat JARs, you should wonder how to choose Tomcat version included in this runnable? Unfortunately I couldn't find any simple option, so we must fall back to explicitly redefining plugin dependencies (version 2.0 has hardcoded 7.0.30 Tomcat). It's quite boring, but not that complicated and might be useful for future reference:

<properties>
    <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
    <tomcat7Version>7.0.33</tomcat7Version>
</properties>

<build>
    <plugins>
        <plugin>
            <groupId>org.apache.tomcat.maven</groupId>
            <artifactId>tomcat7-maven-plugin</artifactId>
            <version>2.0</version>
            <executions>
                <execution>
                    <id>tomcat-run</id>
                    <goals>
                        <goal>exec-war-only</goal>
                    </goals>
                    <phase>package</phase>
                    <configuration>
                        <path>/standalone</path>
                        <enableNaming>false</enableNaming>
                        <finalName>standalone.jar</finalName>
                        <charset>utf-8</charset>
                    </configuration>
                </execution>
            </executions>
            <dependencies>
                <dependency>
                  <groupId>org.apache.tomcat.embed</groupId>
                  <artifactId>tomcat-embed-core</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-util</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-coyote</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-api</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-jdbc</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-dbcp</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-servlet-api</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-jsp-api</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-jasper</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-jasper-el</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-el-api</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-catalina</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-tribes</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-catalina-ha</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
                <dependency>
                  <groupId>org.apache.tomcat</groupId>
                  <artifactId>tomcat-annotations-api</artifactId>
                  <version>${tomcat7Version}</version>
                </dependency>
            </dependencies>
        </plugin>
    </plugins>
</build>
In the next article we will learn how to tame these pesky Tomcat internal logs appearing in the terminal (java.util.logging...) In the meantime I discovered and reported MTOMCAT-186 Closing executable JAR does not call ServletContextListener.contextDestroyed() - have look if this is a deal breaker for you.

1 - it might be a good idea to specify different directory using -extractDirectory and clean it before every restart with -resetExtract.

Comments

  1. Thanks for that trick.
    I got one problem: I wrote a little REST-servlet with JAX-RS, working fine when executed directly inside Eclipse with Tomcat7. Then I made a executable .jar-file according to your instructions but my servlet doesn't work. It's able to start and no errors are given but me REST-servlet isnt responding to any HTTP-Request anymore (neither a result nor an error page is shown). My servlet uses some external jars (like jersey, jaxb,...), I ensured that Maven copies these libs into the target folder. Any idea?

    ReplyDelete
    Replies
    1. were you able to fix this? I am having the this issue and unable to fix it

      Delete
  2. Remember about registering the rest classes inside your Application class (the one with ApplicationPath). I noticed that using jersey inside standalone jar requires that in compare of using deployment on tomcat where registering just package is working

    ReplyDelete
    Replies
    1. Can you please eloborate on how to register the rest class in the application class?

      Delete
  3. I have followed your instructions and get the error:

    java.io.FileNotFoundException: C:\Users\Home\.extract\webapps\test.war (The system cannot find the file specified)

    It happens only on Windows and on macOS in runs perfectly. Do you now how to make it run on Windows?

    ReplyDelete
  4. Thank you sir, it is a great article

    ReplyDelete
